CS5523,兼容MP2456，0.6A，60V，1.0MHz降压芯片

DESCRIPTION

        The CS5523R  is a monolithic,step-down,switch mode converter with a built-in power MOSFET.It achieves a 0.6A peak-output current over wide input supply range with excellent load and line regulation. C urrent-mode operation provides a fast transient response include cycle-by-cycle current limiting and thermal shutdown.The CS5523R requires aminimal number of readily-available external components.The CS5523R is available in SOT23-6L package.

FEATURES

0.6A peak Output Current

700mΩ Internal Power MOSFET

Capable to Start Up with Big Output Capacitor

Stable with Low-ESR Ceramic Output Capacitors

Up to 90% Efficiency

Fixed 1.0MHz Freqiency

Theermal Shutdown

Cycle-by-Cyble Over-Current Protection

Wide 4.5V-to-60V Operating Input Range

100% Duty Cycle Low Dropout Operation

APPLICATIONS

Power Meters                                                       Battery Chargers

Distributed Power Systems                                   WLED Drivers

Pre-Regulator for Linear Regulators

Package

SOT23-6L

更多资料请与我们联系！
